1000L LPE Extraction System
  • Volume: 2x500L vessel holds up to 200-300 pound of dried and ground material
  • Pressure: Maximum system operating pressure 12 bar
  • Power consumption [installed]: 150 kW
  • Temperature: max 85°C (185°F)
  • Materials: 304 stainless steel
  • Vessel: interior is polished to food grade level
  • Closures: ASME flange, both ends
  • Sealing: PTFE flat seals
  • Temperature measurement: Pt100 sensors
  • Water Jacket volume: 200 Liters (53 gallons)
  • Safety: spring loaded safety relief valve
  • Raw material feeding: vacuum mode
  • Residue removal: vacuum mode, quick closure
  • Raw material agitation: low speed stirrer
  • Separator: Jacketed separator/collection vessel
  • Volume: 1 pieces x 150 Liters
  • Pressure: Maximum system operating pressure 12 bar
  • Temperature: max 85°C (185°F)
  • Materials: 304 stainless steel
  • Cleaning: Manual by direct access
  • Safety: spring loaded safety relief valve
  • Flow path: from extractor to separator is continuous diameter with no constrictions
  • Construction: Plate type and shell & tube type
  • Materials: all 304 stainless steel
  • Cooling/Heating: R134a refrigerant
  • Refrigeration: heat pumping
  • Temperature range: 20°C to 45°C (68°F to 113°F)
  • Maximum refrigerant content: 1000 kg
  • Skids number: 1 piece
  • Height: 3,00mm
  • Length: 5,000mm
  • Width: 5,000 mm
  • Total weight: app. 12,000 kg
  • Floor mounting area: min. 60 m²
  • Ceiling height: 5.5 m
  • Functions: Fully automatic programmable Logic Controller (PLC) touch screen interface with first level safety functionality and user programmable pressure, temperature, and time.
  • Safety: Pressure transducers monitor system pressure and shut down system to prevent accidental over-pressurization/safety valves.
